Omron G3MB-202P Solid State Relay – 24V DC Trigger, 2A Output for AC Load Control

The Omron G3MB-202P, a 24V version, is a highly reliable solid state relay (SSR) engineered for the purpose of switching AC loads via a 24V DC control signal. This compact relay, featuring optical isolation and silent switching, is perfectly suited for industrial automation, HVAC control, and embedded electronics applications.

Key Features

The Omron G3MB-202P Solid State Relay comes with a range of impressive features:

• Control Voltage: 24V DC – ideal for PLCs and industrial control circuits 🔋
• Load Capacity: 100–240V AC at up to 2A ⚡
• Contactless Switching: Eliminates mechanical wear or clicking sounds 🔇
• Optical Isolation: Provides high safety and protection from voltage spikes 🛡
• Built-in Snubber Circuit: Ensures safe operation with inductive loads 🔥
• Compact SIP Package: Easy to integrate into PCBs and control boards 📦

Typical Applications

This solid state relay is typically used in:

• Industrial automation systems 🏭
• HVAC equipment control 🌡
• AC lighting and appliance switching 💡
• PLC-controlled AC load switching 🔩
• Embedded and IoT control systems with 24V logic 🔧

Technical Specifications 📊

• Model: G3MB-202P (24V version)
• Input Voltage: 24V DC
• Load Voltage: 100–240V AC
• Load Current: Max 2A
• Switch Type: Zero-cross turn-on
• Isolation: Photocoupler
• Package: SIP (Single Inline Package)

Package Includes 📦

• 1 × Omron G3MB-202P 24V 2A Solid State Relay
